Available inner widths Bi: 15 to 50mmAvailable bend radii R: 28 to 180mmPitch: 30.5mm/link = 33 links/m
DISCONTINUED MODEL For new designs, we recommend the improved e-chain® Series B15, E2 mini Series 15 old is available from stock in limited numbers. Product support and storage are limited as of 2012. For questions, please refer to your igus® contact person. Thank you for your understanding to the E2 mini series B15
* The required clearance height is HF = H + 20 mm (at 1.5 kg/m fill weight), which should be observed in all types of applications. Please contact us if you have particularly confined space requirements.
** The calculated length corresponds to the chain length without mounting brackets.
A=Moving end, B=Fixed endPitch: 30,5mmChain links per m: 33Travel: SChain length = S/2 + K
The unsupported length depends on fill weightX axis: unsupported length in m FLB/FLGY axis: fill weight in kg/mLower scale: travel S in mFLB = unsupported with permissible sagFLG = unsupported with straight upper run
Samples and catalog order
E-Chain® Expert call
Service life calculation
Ask the product expert
Designing with igus®
Interior separation possible
Mounting bracket with and without strain relief tiewrap plates
4 widths, 9 bend radii
Other installation types
Option 1: Separators
Standard mounting brackets
Steel mounting brackets, one-part.
Steel mounting brackets, two-piece
Cross section through one-piece guide trough with glide bar(for dimensions C and D, refer to the delivery table)
