Plastic-steel hybrid energy chain serie YE.56 | Strong, shake-proof and compact | Inner height: 56mm

1 of 6

Plastic-steel hybrid energy chain serie YE.56 | Strong, shake-proof and compact | Inner height: 56mm

Inner height hi: 56mm
Inner widths Bi: 100 - 600mm
Bend radii R: 100 - 500mm
Pitch: 91mm
No screws, rivets or bolts which can become loose under vibration
YE.56: 61% more unsupported length compared to the E4.56 series
High tensile strength
Easy installation - plastic outer links with flange for easy e-chain link assembly

Item no.

YE.56.10.100.0

Inner width [Bi] [mm]

100

Bend radius [R] [mm]

100

50% stronger than pure plastic energy chains and 50% lighter than pure steel energy chains*. No rivets, no screws. e-chains® links open quickly for easy cable replacement. Steel or plastic does not have to be an either-or decision. In order to reach the highest possible unsupported length with the lowest possible weight, so-called hybrid e-chains® are ideal, combining the best properties of steel and plastic.

YE.56: 61% more unsupported length compared to the E4.56 series
High tensile strength
Easy installation - plastic outer links with flange for easy e-chain link assembly

Up to 4 years guarantee: Guaranteed service life this series according to the guarantee conditions. Further information: Guarantee for energy chains

Certificates and standards

When to use it?

Almost 50% lighter than a pure steel chain of comparable size
50% longer unsupported length than a comparable plastic e-chain®
High tensile strength
Very easy installation - plastic outer plates with flange for easy e-chain® link assembly
No screws, rivets or bolts which can become loose under vibration
Tough: steel mounting brackets with attachment options from any side
High ease of movement due to plastic pin connections, high tensile force absorption
Wide range of cable- and hose-friendly interior separation
Available as ready-to-install readychain® system with cables, hoses and hydraulic components

When not to use it?

When greater dynamics are required: E4.56 series
When pure plastic e-chains® are required: E4.56 series
When a fully enclosed e-tube is required: R4.56 series
For long travels gliding: P4.56 series

Unsure whether it fits?

Up to 4 years guarantee

We offer a guarantee of up to four years on energy chains.
