smart plastics iSet - Intelligent system solution for retrofitting E4.1 energy chains | For inner widths up to 250mm | For chain lengths from 10m to 30m

This smart plastics complete retrofit kit consists of:

i.Sense - condition monitoring components:

i.Sense EC.P for monitoring the push/pull forces
i.Sense EC.B for breakage monitoring
i.Sense: module II for installation in the switch cabinet
Connecting cables

i.Cee - predictive maintenance Components:

i.Cee: plus module II
i.Cee LIVE Dashboard on the local network
SMS module: for alerting without http connection
Wear sensors

Industry 4.0 - smart cables

Sensor for intelligent cables | i.Sense CF.P ... It likes to "stay" on the cable. Click here for more information:

smart plastics 3D CAD Files

For your CAD engineering: STEP, DWG, TIFF, 3D PDF, ...

Ask the IoT expert

smart plastics support request

Product description

Product Description

Permanent monitoring of the pull/push forces by i.Sense EC.P (a.o. with 3D data, function video, ...) sensors on the moving end
Monitoring the energy chain for breakage (i.Sense EC.B (a.o with 3D data, function video, ...))
Evaluation of the sensor data in the module
Lightning-fast information to PLC in case of unusual events
Service life calculation based on actual usage (determined by wear sensors)
Maintenance management
SMS - Alerting

Application Parameters:

Sliding e-chain E4.28
Centre fixed
Inner width up to 250mm
Switch cabinet position on the moving end (MN) or fixed end (FP)
Motion profile recording via customer SPS / PLC

_{This smart plastics complete set for retrofitting does not include the initial product, the energy chain itself. Prices for sets with chainflex cable do not include copper surcharge.}
